Altera DE3 |
FPGA device |
Stratix II EP3SL150~340 |
| Speed Grade |
C3,C2 |
| FPGA logic elements(LEs) |
142,000~338,000 |
| SDRAM |
- |
| SRAM |
- |
| FLASH |
- |
| DDR II |
DDR II SO-DIMM Module |
| SD Card |
SD card soket |
| Audio Codec |
- |
| VGA |
- |
| NTSC/PAL DTV Decoder |
- |
| USB Blaster |
Built-in |
| USB2.0 |
YES (High Speed) |
| RS-232 |
YES |
| Ethernet (10/100) |
- |
| IrDA |
- |
| PS/2 |
- |
| LEDs |
8 |
| Slide Switches |
4 |
| Push Buttons |
4 |
| Expansion Ports |
~520 pins |
| Demo Source Code |
Included |
User Manual |
 |
Demonstrations |
Available Soon! |
|
| |
|
| |
Altera DE2-70 |
FPGA device |
Cyclone II EP2C70F896 |
| Speed Grade |
C6 |
| FPGA logic elements(LEs) |
68416 |
| SDRAM |
64 MB |
| SRAM |
2 MB (SSRAM) |
| FLASH |
8 MB |
| SD Card |
SD card soket |
| Audio Codec |
24-bit CD Quality |
| VGA |
10-bit UXGA |
| NTSC/PAL DTV Decoder |
DTV Decoder x 2 |
| USB Blaster |
Built-in |
| USB2.0 |
YES |
| RS-232 |
YES |
| Ethernet (10/100) |
YES |
| IrDA |
YES |
| PS/2 |
YES |
| LEDs |
25 |
| Toggle Switches |
18 |
| Push Buttons |
4 |
| Expansion Ports |
2 x 40 pins |
| Demo Source Code |
Included |
User Manual |
|
Demonstrations |
Available Soon! |
|
| |
|
| |
Altera DE2 |
FPGA device |
Cyclone II EP2C35F672 |
| Speed Grade |
C6 |
| FPGA logic elements(LEs) |
33216 |
| SDRAM |
8 MB |
| SRAM |
512 KB |
| FLASH |
4 MB |
| SD Card |
SD card soket |
| Audio Codec |
24-bit CD Quality |
| VGA |
10-bit UXGA |
| NTSC/PAL DTV Decoder |
DTV Decoder x 1 |
| USB Blaster |
Built-in |
| USB2.0 |
YES |
| RS-232 |
YES |
| Ethernet (10/100) |
YES |
| IrDA |
YES |
| PS/2 |
YES |
| LEDs |
25 |
| Toggle Switches |
18 |
| Push Buttons |
4 |
| Expansion Ports |
2 x 40 pins |
| Demo Source Code |
Included |
User Manual |
|
Demonstrations |
 |
|
| |
|
| |
LTM |
Product Name |
4.3'' LCD Touch Panel Moudle |
Specifications |
Support 800x480 resulution |
| Support 24-bit parallel RGB interface |
| Built-in contrast, brightness, and gamma modulation |
Demonstrations
(Complete source code included) |
DTV Player |
| Coloer Pattern Generator |
| Picture Viewer |
User Manual |
|
Demonstrations |
Available Soon! |
|
| |
|
| |
D5M |
| Product Name |
5 Mega Pixel Digital Camera Module |
Specifications |
Support 2,592H x 1,944V active pixels |
| Output data in RGB Bayer Pattern format |
| Full resolution is programmable up to15 fps |
Demonstrations
(Complete source code included) |
Digital Camera |
| - |
| - |
| User Manual |
|
Demonstrations |
Available Soon! |
|
